Supported VPN Types

Ubiquiti (Ubnt) devices, such as UniFi Security Gateways (USG), UniFi Dream Machines (UDM), and EdgeRouters, support VPN configurations for secure remote access or site-to-site connections. Here's an overview of setting up a VPN on Ubiquiti hardware:

1. OpenVPN (Remote Access or Site-to-Site)
2. IPSec/L2TP (Site-to-Site or Remote Access)
3. WireGuard (via third-party scripts or newer UniFi OS versions)
4. PPTP (legacy, not recommended due to security flaws)

OpenVPN Setup (Remote Access)

On UniFi OS (UDM/USG)

1. Enable OpenVPN Server:

   • Go to UniFi Network Settings → Teleport & VPN → OpenVPN.
   • Enable the OpenVPN server and configure:
     • Port (default: 1194)
     • Subnet for clients (e.g., 8.0.0/24)
     • DNS settings (e.g., your LAN DNS or 1.1.1).
   • Download the .ovpn client config file.

2. Configure Firewall Rules (if needed):

   • Allow traffic from VPN clients to your LAN under Firewall & Security.

3. Client Setup:

   • Use the .ovpn file with OpenVPN client apps (e.g., OpenVPN Connect).

IPSec VPN (Site-to-Site)

On EdgeRouter or UniFi

1. Phase 1 Settings (Authentication):

   • Encryption: AES-256
   • Hash: SHA256
   • DH Group: 14 (or higher)
   • Lifetime: 28800

2. Phase 2 Settings (Data Transfer):

   • Encryption: AES-256
   • PFS: Enable (DH Group 14)

3. Peer Configuration:

   • Enter the remote gateway IP and pre-shared key (PSK).
   • Define local/remote subnets (e.g., 168.1.0/24 ↔ 0.0.0/24).

WireGuard (Advanced Setup)

WireGuard is not natively supported in UniFi OS but can be installed manually:

On UDM Pro/SE (via SSH)

1. SSH into the device and install WireGuard:

   unifi-os shell
   apt update && apt install -y wireguard

2. Generate keys and configure wg0.conf:

   umask 077; wg genkey | tee privatekey | wg pubkey > publickey

3. Start WireGuard:

   wg-quick up wg0

4. Configure clients (peer devices) with the public key and allowed IPs.

Troubleshooting

• VPN Not Connecting?

  • Check firewall rules (allow UDP ports for OpenVPN/IPSec).
  • Verify subnet conflicts (VPN IP ranges shouldn’t overlap with LAN).
  • Ensure NAT traversal is enabled (for IPSec behind NAT).

• Slow Performance?

  • Use AES hardware acceleration (supported on EdgeRouter/USG).
  • Prefer WireGuard for better speed (if available).

Recommended VPN for UniFi

• Remote Access: OpenVPN (easy setup) or WireGuard (faster).
• Site-to-Site: IPSec (compatible with most enterprise routers).

For UniFi Dream Machine (UDM), the built-in Teleport VPN (based on WireGuard) offers a simple remote-access solution via the UniFi Network app.
